Stile – Metal Sales Stile Manual User Manual
Page 11
STILE
®
PST-11
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
g
UTTer
d
eTail
Double Bead Tape Sealant
Box Gutter
Universal Gutter / Downspout Strap
1
/
4
"-14 x 1
1
/
2
" Woodscrew XL (1'-0" o.c.)
Stile Closure
Stile Starter
Stile Panel
Moisture Barrier (by others)
3
/
16
" x 6" Spacer
Double Bead Tape Sealant
1
/
8
" x
3
/
16
" Pop-Rivet
1
/
4
"-14 x 1
1
/
2
" Woodscrew XL (see below)
sTile
®
v
alley
d
eTail
Valley Plate
Universal Closure
Stile Panel
Double Bead Tape Sealant
1
/
8
" x
3
/
16
" Pop-Rivet (every other rib)
1
/
4
"-14 x 1
1
/
2
" Woodscrew XL (see below)
Valley
3:12 Slope
Minimum
3:12 Slope
Minimum
Moisture Barrier (by others)
#
1
/
4
-14 x 1
1
/
2
" Woodscrew XL
Stile Fastening Pattern
1
/
4
"-
14 x 1
1
/
2
" Woodscrew XL
Stile Fastening Pattern
