PSN-22

SNAP-LOC 24

®

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

CL

9"

3"

ssr r

idge

/h

iP

d

eTail

1

/

4

:12 SLOPE

MINIMUM

Snap-Loc 24 Compression Plate

Double Bead Tape Sealant

SSR Ridge

Snap-Loc 24 Metal Outside Closure

1

/

4

"-14 x 1-

1

/

2

" SD N/W (see below)

Snap-Loc 24 Clip w/ (2) #

1

/

4

-14 x 1

1

/

2

" SD N/W

Snap-Loc 24 Panel

Double Bead Tape Sealant

1

/

4

"-14 x

7

/

8

" Stitch XL (3 per panel)

1

/

4

"-14 x 1-

1

/

2

" SD N/W (see below)

1

/

4

"-14 x 1-

1

/

2

" SD NW

Metal Outside Closure

Snap-Loc 24 Fastening Pattern

1

2

5

4

3

6
