PSN-16

SNAP-LOC 24

®

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

Snap-Loc 24 Panel (bevel cut in field)

Double Bead Tape Sealant

SSR Drop Valley

Snap-Loc 24 Eave Plate

Valley Plate

d

roP

v

alley

d

eTail

6:12 SLOPE

MINIMUM

Snap-Loc 24 Metal inside Closure

1

/

4

"-14 x 1-

1

/

2

" SD N/W (see below)

1

/

4

"-14 x 1-

1

/

2

" SD N/W (1'-0" o.c.)

1

/

4

"-14 x 1-

1

/

2

" SD NW

Metal Inside Closure

1

/

4

"-14 x 1-

1

/

2

" SD NW

Snap-Loc 24 Fastening Pattern

1

2

5

4

3

Line of Tape Sealant

Valley
