PSN-17
SNAP-LOC 24 ®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
ssr s
CUlPTUred
r
ake
(o
n
m
odUle
) d
eTail
Snap-Loc 24 Panel
Double Bead Tape Sealant
Floating Rake Angle
SSR Rake Slide
Rake Angle
SSR Sculptured Rake (on module)
1 /
4
"-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
Double Bead Tape Sealant
#12-14 x 1- 1 /
4
" SD XL (1'-0" o.c.)
#12-14 x 1- 1 /
4
" Shoulder SD (1'-0" o.c.)
SSR Rake Cleat
1 /
4
"-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
ssr s
CUlPTUred
r
ake
(o
n
m
odUle
o
PTion
) d
eTail
