snaP-loC 24
®
CAUTION
In locations where heavy
rainfall or severe ice and
snow may occur, Metal
Sales' standard gutters may
not be suitable for use.
1
/
8
" x
3
/
16
" Pop-Rivet (1 per gutter support)
Snap-Loc 24 Panel
SSR Sculptured Gutter
SSR Gutter Support (every other panel)
s
CUlPTUred
g
UTTer
d
eTail
Double Bead Tape Sealant
#12-14 x 1
1
/
2
" SD XL (2 per gutter support)
6"
e
ndlaP
d
eTail
Snap-Loc 24 Panel
1
/
4
:12 SLOPE
MINIMUM
1
/
4
:12 SLOPE
MINIMUM
Snap-Loc 24 Metal Inside Closure
1
/
4
"-14 x
7
/
8
" Stitch XL (2 per panel)
1
/
4
"-14 x 1-
1
/
2
" SD XL (see below)
Gutter Drip
Eave Plate
#12-14 x 1" SD N/W (1'-0" o.c.)
2"
Snap-Loc 24 Clip W/ (2) #
1
/
4
"-14 x 1
1
/
4
" SD N/W
Snap-Loc 24 Panel (pre-punched)
Snap-Loc 24 Endlap Pad
Pigtail of Endlap Pad
Snap-Loc 24 Compression Plate
1
/
4
"-14 x 1
1
/
2
" SD NW
Metal Inside Closure
#12-14 x 1-
1
/
2
" SD XL
Snap-Loc 24 Fastening Pattern
1
2
5
4
3
Snap-Loc 24 Fastening Pattern
1
/
4
"-14 x 1-
1
/
2
" SD XL
1
2
5
4
3
