Page 21
PSN-21
SNAP-LOC 24
®
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
ssr s
CUlPTUred
h
igh
s
ide
e
ave
d
eTail
snaP-loC 24
®
v
enTed
r
idge
d
eTail
1
/
4
:12 SLOPE
MINIMUM
1
/
4
:12 SLOPE
MINIMUM
Snap-Loc 24 Compression Plate
Double Bead Tape Sealant
SSR Sculptured High Side Eave Break
1
/
4
"-14 x 1-
1
/
2
" SD N/W (see below)
1
/
4
"-14 x
7
/
8
" Stitch XL (3 per panel)
Snap-Loc 24 Metal Outside Closure
1
/
4
"-14 x 1-
1
/
2
" SD N/W (see below)
Snap-Loc 24 Clip W/ (2) #
1
/
4
-14 x 1
1
/
2
" SD N/W
Snap-Loc 24 Panel
Double Bead Tape Sealant
1
/
4
"-14 x
7
/
8
" Stitch XL (1'-0" o.c.)
Snap-Loc 24 Compression Plate
Double Bead Tape Sealant
Vented Ridge Cover
Snap-Loc 24 Metal Outside Closure
1
/
4
"-14 x 1-
1
/
2
" SD N/W (see below)
Snap-Loc 24 Clip w/ (2)
1
/
4
"-14 x 1-
1
/
2
" SD N/W
Snap-Loc 24 Panel
Offset Cleat
1
/
8
" x
3
/
16
" Pop-Rivet (1'-0" o.c.)
#14-13 x 2" Dekfast (1'-0" o.c.)
Double Bead Tape Sealant
Vent Material
Vent Drip
Double Bead Tape Sealant
11"
1"
1
/
4
"-14 x 1-
1
/
4
" SD NW
Metal Outside Closure
Snap-Loc 24 Fastening Pattern
1
2
5
4
3
6
1
/
4
"-14 x 1-
1
/
2
" SD NW
Metal Outside Closure
Snap-Loc 24 Fastening Pattern
1
2
5
4
3
6
