Mayline Maytrix Frame - Manual

1. Insert End Caps (E1) into upper
ends of Frame (1).
NOTE: Screws, Washers, and Hex
Nuts will be used later during the
assembly process.
ASSEMBLY INSTRUCTIONS
MAYTRIX LAN FURNITURE
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
COMPONENTS:
REF.# QTY. DESCRIPTION PART No.
1 1 FRAME ASSEMBLY CALL~~**
HARDWARE BAG (PART No. A4359) *for individual item, order that part number
REF. # QTY. DESCRIPTION PART No.
E1 2 END CAP F672*
E2 2 1/4-20 HEX NUT T29*
E3 4 WASHER W13*
E4 2 1/4-20 X 2 1/2 SCREW X317*
** Denotes Color Code
~~Denotes Size
Frame (1)
End Cap (E1)
NOTE: Please count and inspect all pieces before disposing
of any carton or packing materials.
TM
(1)
