9400 Technology applications | Actuator – speed
Parameter setting & configuration
Parameterisable function blocks
4.12.3 SpeedRamp
Is an instance of Function
L_SdSpeedSet Ramp generator for speed setpoint
Speed setpoint conditioning (C 18)
Parameter Possible settings Information
C03500/1...15 -200.00 % 200.00 Fixed setpoint 1...15
C03501 0 15 Active setpoint
• Read only
C03502 0.000 s 1000.000 Basic acceleration time
• Initialisation: 1.000 s
C03503 0.000 s 1000.000 Basic deceleration time
• Initialisation: 1.000 s
C03504 0.000 s 10.000 Basic S-ramp time
• Initialisation: 0.100 s
C03507 Polarity of bStop input
0 Active HIGH
1 Active LOW
C03508 0.00 % 100.00 Setpoint tolerance reached
• Initialisation: 1.00 %
C03512/1...15 0.000 s 1000.000 Acceleration time 1...15
• Initialisation: 0.000 s
C03513/1...15 0.000 s 1000.000 Deceleration time 1...15
• Initialisation: 0.000 s
C03514/1...15 0.000 s 1000.000 S-ramp time 1...15
• Initialisation: 0.000 s
C03515 0 15 Active ramp parameters
• Read only
C03520 Profile mode
• Read only
0 Profile generation with linear ramps
• Referred to the reference speed
(C00011).
1 Profile generation with jerk
limitation (S-shaped ramps)
10 Profile generation with linear ramps
• Referred to the reference speed
(C00011).
• At an edge change at the input
bStop referred to the current
setpoint (constant time).
• The setpoint applied at the input
dnExtSpeedSetpoint_n is used as
the start value.
C03521 -200.00 % 200.00 Setpoint at the input
• Read only
C03522 -200.00 % 200.00 Target setpoint
• Read only
C03523 -200.00 % 200.00 Setpoint at the output
• Read only
