9400 technology applications | actuator – speed – Lenze E94AxHE Technology Application Actuating drive - Speed User Manual
Page 28
9400 Technology applications | Actuator – speed
Parameter setting & configuration
Brake control
28
L
EDS94TA10010xxxx EN 1.1 - 10/2008
Control/setpoint inputs of the function
Signal configuration
Lenze setting
Control/setpoint input
(Multiplexer parameters)
FALSE Open brake (release)
C03165/1
FALSE Activate starting torque 2
C03165/2
FALSE Keep open brake at standstill
C03165/3
FALSE Brake status signal
C03165/4
FALSE Activate brake test
C03165/5
FALSE Grind brake
C03165/6
0 % Additional torque
C03166
