About this documentation
Conventions used
6
Lenze · PLC Designer | Migration of V2.x projects · 1.2 EN - 02/2013
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.1
Conventions used
This documentation uses the following conventions to distinguish between different types of infor-
mation:
Type of information
Writing
Examples/notes
Spelling of numbers
Decimal separators
Point
The decimal point is always used.
For example: 1234.56
Text
Version information
Text colour blue
Information that is only valid for or from a certain software
version of the controller is marked accordingly in this
manual.
Example:
This function extension is available from software
version V3.0!
Program name
» «
»PLC Designer«...
Window
italics
The Message window ... / The Options dialog box...
Variable identifier
Set bEnable to TRUE to...
Control element
bold
The OK button... / The Copy command... / The Properties
tab... / The Name input field...
Sequence of menu
commands
If the execution of a function requires several commands,
the individual commands are separated by an arrow: Select
File
Open to...
Shortcut
Press
If a command requires a combination of keys, a "+" is placed
between the key symbols:
Use
Program code
Courier
IF var1 < var2 THEN
a = a + 1
END IF
Keyword
Courier bold
Hyperlink
Optically highlighted reference to another topic. In this
documentation it is activated by mouse-click.
Symbols
Page reference
Optically highlighted reference to another page. In this
documentation it is activated by mouse-click.
Step-by-step instructions
Step-by-step instructions are indicated by a pictograph.
