Lenze TCF Series Drives Modbus Communications - Manual (Page 27)

23 RG-TFMOD
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value) Factory Default
130 (82H) 80 Drive Mode 01 - Constant V/Hz
02 - Variable V/Hz
03 - Enhanced Constant V/Hz
04 - Enhanced Variable V/Hz
05 - Vector Speed
06 - Vector Torque 01 - Constant V/Hz
131 (83H) 81 Auto Calibration 00 - Calibration Not Done
01 - Calibration Cycle Enabled
02 - Calibration Complete 00 - Calibration Not Done
132 (84H) 82 Current Loop P Gain 0 - 1600 (0.00 - 16.00) 25 (0.25) 2
133 (85H) 83 Current Loop I Gain 120 - 9990 (12 - 999 msec) 650 (65 msec)
134 (86H) 84 Stator Resistance 0 - 6400 (0.00 - 64.00 ohms) refer to Note 8 0 (0.00 ohms) 2
135 (87H) 85 Motor Rated Speed 3000 - 650000 (300 - 65000 RPM) 17500 (1750 RPM)
136 (88H) 86 Motor Rated Amps 0 - 480 (0.0 - 48.0 amps) 0 (0.0 amps)
137 (89H) 87 Motor Rated Volts 0 - 6000 (0 - 600 VAC) 0 (0 VAC)
138 (8AH) 88 Motor Base Frequency 250 - 5000 (25 - 500 Hz) 600 (60 Hz)
141 (8DH) 91 Motor Cosine Phi 40 - 99 (0.40 - 0.99) 90 (0.90) 2
142 (8EH) 92 Motor Inductance 0 - 20000 (0.0 - 2000 mH) refer to Note 8 0 (0.0 mH)
143 (8FH) 93 Torque Limit 0 - 4000 (0 - 400 %) 1000 (100 %)
144 (90H) 94 Drive Personality (Read Only) Refer to section 5.3 Drive Size EPM copy of Drive Index
145 (91H) 95 Motor Current (Read Only) N/A
146 (92H) 96 Torque Percent (Read Only) N/A
1 = Drive's programming parameter number
2 = Two decimal places assumed (hundredths)
