RG-TFMOD 22
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value) Factory Default
93 (5DH) 43 Serial Address 1 - 247 1
94 (5EH) 44 Password 000 - 999 225
95 (5FH) 45 Speed at Min Signal 0 - 9990 (0.0 - 999 Hz) 0 (0.0 Hz)
96 (60H) 46 Speed at Max Signal 0 - 9990 (0.0 - 999 Hz) 600 (60.0 Hz)
97 (61H) 47 Clear History 01 - Maintain
02 - Clear 01 - Maintain
98 (62H) 48 Program Selection 01 - User Settings
02 - OEM Settings
03 - Reset OEM
04 - Reset 60
05 - Reset 50
06 - Translate 04 - Reset 60
99 (63H) 49 TB-13D Input 01 - None
02 - 0-10 VDC
03 - 4-20 mA
04 - Preset Speed #1
05 - Start Forward
06 - External Fault
07 - Remote Keypad Control
08 - Dynamic Brake Fault
09 - Auxiliary Stop
10 - Accel / Decel #2 01 - None
Diagnostic – Read Only Parameters! (50# - 60#)
100 (64H)
50 FAULT HISTORY Must Read 4 Words (Read Only) See Note [4]
101 (65H) 51 SOFTWARE VERSION Must Read 1 or 4 Words (Read Only) See Note [5]
102 (66H) 52 BUS VOLTAGE [%] 0-250 (MIN 0% MAX 250%) Read Only
103 (67H) 53 ACTUAL MOTOR
VOLTAGE [%] 0-250 (MIN 0% MAX 250%) Read Only
104 (68H) 54 MOTOR LOAD [%] 0-250 (MIN 0% MAX 250%) Read Only
105 (69H) 55 0-10VDC analog input
[100% = 10VDC] 0-250 (MIN 0% MAX 250%) Read Only
106 (6AH) 56 4-20mA analog input
[100% = 20mA] 0-250 (MIN 0% MAX 250%) Read Only
107 (6BH) 57 DIGITAL I/O SERIAL READ - DIGITAL I/O REPRESENTATION See Note [6]
108 (6CH) 58 DIGITAL I/O SERIAL READ - DIGITAL I/O REPRESENTATION See Note [6]
109 (6DH) 59 TB30 OUTPUT 0-250 (MIN 0% MAX 250%) Read Only
123 (7BH) 73 HEATSINK TEMP 0-255 (degrees C) Read Only
125 (7DH) 75 INPUT Assertion Level 01 - Low
02 - High 02 - High
1 = Drive's programming parameter number
