Page 16
RG-TFMOD 12
Drive Control & Communication
NOTE 1 - Drive Control
• During each write to Register #1 only one bit should be set in the drive control word.
• If more than 1 bit is set, the drive responds to stop bit only.
• If stop bit is not set, but more than 1 bit is set, drive responds with exception 04.
NOTE 2 - Drive Family
• The QC Series drives return 64 (40H)
• The
smd Series drives return 69 (45H)
• The MC Series drives return 65 (41H)
• The TCF Series drives return 70 (46H)
• The SC Series drives return 66 (42H)
• The
Tmd Series drives return 71 (47H)
• The MCH Series drives return 68 (44H) • The SMV Series drives return 72 (48H)
5.3 Drive Size - Register 21
Table 8 lists the drive index number, voltage, input phase and horsepower ratings for the TCF Series Drives.
The "Drive Index #" is the RAM copy of Register 21.
Table 8: TCF Drive Index
Drive
Index
#
Voltage
Input
Phase
HP
Drive
Index
#
Voltage
Input
Phase
HP
Drive
Index
#
Voltage
Input
Phase
HP
01
208/240
1
0.5
25
400/480
3
0.5
40
480/590
3
0.5
02
208/240
1
1
26
400/480
3
1
41
480/590
3
1
03
208/240
1
1.5
27
400/480
3
1.5
42
480/590
3
1.5
04
208/240
1
2
28
400/480
3
2
43
480/590
3
2
05
208/240
1
3
29
400/480
3
3
44
480/590
3
3
06
208/240
1
5
30
400/480
3
5
45
480/590
3
5
13
208/240
3
0.5
31
400/480
3
7.5
46
480/590
3
7.5
14
208/240
3
1
32
400/480
3
10
47
480/590
3
10
15
208/240
3
1.5
33
400/480
3
15
48
480/590
3
15
16
208/240
3
2
34
400/480
3
20
49
480/590
3
20
17
208/240
3
3
35
400/480
3
25
50
480/590
3
25
18
208/240
3
5
36
400/480
3
30
51
480/590
3
30
19
208/240
3
7.5
37
400/480
3
40
52
480/590
3
40
20
208/240
3
10
38
400/480
3
50
53
480/590
3
50
21
208/240
3
15
39
400/480
3
60
54
480/590
3
60
22
208/240
3
20
23
208/240
3
25
24
208/240
3
30
