5
Cascade A Out Connector
Provides an attachment point for connecting this unit to
another unit via the cascade cable. A return cable from
another unit’s Cascade A Out connector to this unit’s
Cascade A In connector completes the stack connection
(see the example shown in
).
Unit Select Switch
The Unit Select switch (up = Base) determines the base
unit for the stack configuration (see
). The Unit Select switch status is
displayed on the BayStack 450 LED display panel (see the
Using the BayStack 450 10/100/1000 Series Switch guide
for details). When in the Base (up) position, all other Unit
Select switches in the stack configuration must be set to
Off (down).
Note:
For stacking three or more units
(maximum 8 units per stack), order the optional
1 meter (39.27 inch) cascade max-return cable
(Bay Networks Order No. AL2018001).
