30
5.
Reconnect the cascade cable from unit 2 to the
Cascade A In connector of (new) unit 5.
6.
Connect a cascade cable from the Cascade A Out
connector of unit 5 to the Cascade A In connector
of unit 6.
7.
Connect a cascade cable from the Cascade A Out
connector of unit 6 to the Cascade A In connector
of unit 3.
8.
Renumber the order of the units for the new stack
configuration (if desired).
You can renumber the unit numbers as described in
“Setting Up the Stack Configuration” in the Using the
BayStack 450 10/100/1000 Series Switch guide.
Adding Units to the End of a Stack
To add one or more units to the end of a stack,
complete the following steps:
1.
Determine the position of the new units in the
existing stack (
).
For example, the shaded units (units 5 and 6) in
show the two new units to be added to the
stack. The new units are numbered as unit 5 and unit 6
because they are additions to the end of an existing 4
unit stack.
