Technical data
Protective insulation
6
EDKMF2113 DE/EN/FR 5.1
73
l
H1_Daten−AlleMaßeInMM
Protocol data
Field Values
Maximum number of
controllers Dependent on INTERBUS master (e.g. Phoenix Contact G4 master).
For the following data, always the smaller value applies dependent
on the fact, whether PCP communication is available or not:
l with PCP communication: 62 or
l without PCP communication: 256/number of PD
Process data words (PD) 1 ... 10 (selectable) Lenze setting: 2 words
Parameter data words (PCP) 0, 1, 2, 4 Lenze setting: 1 word
Maximum number of data
words As a maximum, the data word sum (PD + PCP) is to amount to 10
words.
INTERBUS ID
(module ID) Module ID for set length
3 = 0x03 PCP, 0 words
227 = 0xE3 PCP, 1 word
224 = 0xE0 PCP, 2 words
225 = 0xE1 PCP, 4 words
Maximum PDU length 64 bytes
Supported PCP services Initiate, Abort, Status, Identify, Get−0V−long, Read, Write
