Legend for fold−out page
Pos. Description Detailed
information
0 Status display (green) for voltage supply
^ 69 1 Status display (yellow ) for INTERBUS communication
2 Status display (red/green) of drive
3 DIP switches
l for configuration
– of process data words ^ 62
– of PCP data words ^ 63
– of ID code ^ 63
– of baud rate ^ 65
l for selecting the AIF−CTRL device control or DRIVECOM profile 21 ^ 64
4 INTERBUS output (OUT), Sub−D socket connector, 9−pole ^ 59
5 INTERBUS input (IN), Sub−D pin connector, 9−pole ^ 57
6 PE connection (only with 82XX)
7 Fixing screw
8 Plug connector, connection for external voltage supply ^ 49
9 Nameplate ^ 41
0Fig. 0Tab. 0
I
Tip!
Documentation and software updates for further Lenze products can be found
on the Internet in the "Services & Downloads" area under
http://www.Lenze.com
