Elektrische installation, Verdrahtung, H1_e_inst−verbdg zum ibs – Lenze EMF2113IB User Manual
Page 17
Elektrische Installation
Verdrahtung
EDKMF2113 DE/EN/FR 5.1
17
l
H1_E_INST−verbdg zum IBS
Verdrahtungsbeispiel
£
400
m
£ 400 m
3.1
INTERBUS-Loop 200 m
£
£ 20 m
82XX
+
2112
8200 vector
+
2113
93XX
+
2113
82XX
+
2111
93XX
+
2112
8200 vector
+
2112
3.1
3.1
3.2
3.2
3.2
3.2
4.2
4.2
4.2
4.2
2
4
4.1
4.1
4.1
1
3
2131IBU003
Abb. 2
Verdrahtungsbeispiel, INTERBUS (Übertragungsrate 500 kBit/s)
