10 Code table
Overview
Code Subcode Index Designation See
C0002 − 0x5FFD
(24573) Parameter set management ^ 67
C1500 − 0x5A23
(23075) Software ID ^ 62
C1501 − 0x5A22
(23074) Software creation date ^ 62
C1502 1 ... 4 0x5A21
(23073) Display of the software ID ^ 62
C1503 1 ... 4 0x5A20
(23072) Display of the software creation date ^ 62
C1510 − 0x5A19
(23065) Configuring process input data ^ 58
C1511 − 0x5A18
(23064) Configuring process output data ^ 59
C1512 − 0x5A17
(23063) Enable process output data ^ 60
C1513 − 0x5A16
(23062) Response monitoring time of the PCD
communication ^ 61
C1514 − 0x5A15
(23061) Monitoring response to PCD
communication fault ^ 61
C1515 − 0x5A14
(23060) Process data specification ^ 60
C1520 1 ... 10 0x5A0F
(23055) Display of all words to the master ^ 63
C1521 1 ... 10 0x5A0E
(23054) Display of all words from the master ^ 63
C1522 1 ... 16 0x5A0D
(23053) Display of all process data words to the
standard device ^ 64
C1523 1 ... 16 0x5A0C
(23052) Display of all process data words from
the standard device ^ 65
C1525 − 0x5A0A
(23050) Display of the current setting of the DIP
switches S2 ... S4 ^ 65
C1530 − 0x5A05
(23045) INTERBUS diagnostics ^ 66
C1531 1 ... 4 0x5A04
(23044) Bus counter ^ 66
