Page 58: Communication−relevant lenze codes
Codetabelle
Communication−relevant Lenze codes
l
58
EDS82ZAFIC EN 2.0
10.1
Communication−relevant Lenze codes
C1510:
Configuring process input data
Code
C1510
Name
Configuring process input data
Index
0x5A19 (23065)
Subcode
Lenze
Values
Access
Data type
1
PIW1
18
see table below
rw
FIX32
2
PIW2
3
3
PIW3
4
4
PIW 4
5
þ Parameter set transfer
The assignment of the bit status information or actual values of the controller to the max.
4 process input data words (PIW) of the master can be configured freely.
)
Note!
For reasons of compatibility, subcodes 5 and 6 can also be read and written
with modules from software version V3.0. However, this has no effect.
Selection
Scaling
1
FIF status word 1 (FIF−STAT1)
16 bits
2
FIF status word 2 (FIF−STAT2)
16 bits
3
Output frequency with slip (MCTRL1−NOUT+SLIP)
±24000
º ±480 Hz
4
Output frequency without slip (MCTRL1−NOUT)
±24000
º ±480 Hz
5
Apparent motor current (MCTRL1−IMOT)
2
14
º 100 % rated device current
6
Actual process controller value (PCTRL1−ACT)
±24000
º ±480 Hz
7
Process controller setpoint (PCTRL1−SET)
±24000
º ±480 Hz
8
Process controller output (PCTRL1−OUT)
±24000
º ±480 Hz
9
Device utilisation (MCTRL1−MOUT)
±2
14
º ±100 % rated motor torque
10
DC−bus voltage (MCTRL1−DCVOLT)
16383
º 565 VDC at 400 V mains
16383
º 325 VDC at 230 V mains
11
Ramp function generator input (NSET1−RFG1−IN)
±24000
º ±480 Hz
12
Ramp function generator output (NSET1−NOUT)
±24000
º ±480 Hz
13
FIF−OUT.W1
16 bits or 0 ... 65535
14
FIF−OUT.W2
16 bits or 0 ... 65535
15
FIF−OUT.W3
0 ... 65535
16
FIF−OUT.W4
0 ... 65535
17
DRIVECOM control word (DRIVECOM−CTRL)
16 bits
18
DRIVECOM status word (DRIVECOM−STAT)
16 bits
