Codetabelle
Communication−relevant Lenze codes
10
l
60 EDS82ZAFIC EN 2.0
C1512:
Enable process output data
Code
C1512
Name
Enable process output data
Index
0x5A17 (23063)
Subcode Lenze Values Access Data type
− 1 1 [1] 255 rw FIX32
þ Parameter set transfer
When C1511 is changed, the process output data is automatically locked to ensure data
consistency.
C1512 serves to unlock single or all process output data words (POW) again.
The decimal value of the bit settings enables any combination of the process output data
words (POW).
ƒ 0 = Lock output word
ƒ 1 = Unlock output word
Valency of the bit settings
POW 4 POW 3 POW 2 POW 1
2 3 2 2 2 1 2 0
The value 16 (0x10) in code C1512 serves to enable all process output data.
C1515:
Process/parameter data specification
Code
C1515
Name
Process/parameter data specification
Index
0x5A14 (23060)
Subcode Lenze Values Access Data type
− 0 0, 1, 4, 5 rw FIX32
11 ... 14
21 ... 23
þ Parameter set transfer
This code serves to change the number of process and parameter data words:
Values Description
0, 1, 4, 5 The configuration resulting from the settings of the DIP switches S2 ... S4 is
accepted according to the valency entered.
11 ... 14 l No PCP
l 11 (1 word PCD) ... 14 (4 words PCD)
21 ... 23 l 1 word PCP
l 21 (1 word PCD) ... 23 (3 words PCD)
)
Note!
ƒ The settings of this code only become active if the DIP switches S2 ... S4 are
set to ON (
¶ .
ƒ Switch off the voltage supply of the function/communication module and
then on again to activate changed settings.
