Codetabelle
Diagnostics
10
l
63 EDS82ZAFIC EN 2.0
C1520:
Display of all words to the master
Code
C1520
Name
Display of all words to the master
Index
0x5A0F (23055)
Subcode Lenze Values Access Data type
1 PIW 1 g 0 [1] 65535 r U16
2 PIW 2
3 PIW 3
4 PIW 4
o Parameter set transfer
Display of the process input data words 1 ... 4 under the single subcodes. All words are
displayed, but only the configured ones are valid.
C1521:
Display of all words from the master
Code
C1521
Name
Display of all words from the master
Index
0x5A0E (23054)
Subcode Lenze Values Access Data type
1 POW1 g 0 [1] 65535 r U16
2 POW2
3 POW3
4 POW4
o Parameter set transfer
Display of the process output data words 1 ... 4 under the single subcodes. All words are
displayed, but only the configured ones are valid.
