Codetabelle
Diagnostics
10
l
66 EDS82ZAFIC EN 2.0
C1530:
INTERBUS diagnostics
Code
C1530
Name
Diagnostics
Index
0x5A05 (23045)
Subcode Lenze Values Access Data type
− g 0 0 0 r FIX32
o Parameter set transfer
C1531:
Bus counter
Code
C1531
Name
Bus counter
Index
0x5A04 (23044)
Subcode Lenze Values Access Data type
1 ... 4 g 0 [1] 65535 r FIX32
o Parameter set transfer
Dependent on the subcode, the following bus states are displayed:
ƒ Subcode 1: Data cycles per second
ƒ Subcode 2: Total data cycles
ƒ Subcode 3: Reserved (value is always ’0’)
ƒ Subcode 4: Reserved (value is always ’0’)
I
Tip!
When the maximum count value ’65535’ has been reached, the counter
restarts at value ’0’.
