Commissioning
Defining the user data length
6
l
31 EDS82ZAFIC EN 2.0
Settings via code
ƒ DIP switches S2 ... S4 = ON
ƒ Set the number of data words (PCD + PCP) via C1515.
Code
C1515
Name
Process/parameter data specification
Index
0x5A14 (23060)
Subcode Lenze Values Access Data type
− 0 0, 1, 4, 5 rw FIX32
11 ... 14
21 ... 23
Values Description
0, 1, 4, 5 The configuration resulting from the values corresponding to the set DIP switch
positions becomes active.
11 ... 14 l No PCP
l 11 (1 word PCD) ... 14 (4 words PCD)
21 ... 23 l 1 word PCP
l 21 (1 word PCD) ... 23 (3 words PCD)
