Safety engineering
Safety functions
Safe PROFIsafe connection
1
1.3
1.3.5

1.3-16 EDS94AYAD EN 2.2
Error number Description
64 The Profisafe target address set does not comply with the parameter
F_Dest_Add.
65 The F_Dest_Add parameter has the invalid value 0x0000 or 0xFFFF.
66 The F_Source_Add parameter has the invalid value 0x0000 or 0xFFFF.
67 The F_WD_Time parameter has the invalid value 0 ms.
68 The F_SIL parameter does not have the valid value 0 ... 2.
69 The F_CRC_Length parameter does not have the valid value 2.
70 The version of the PROFIsafe parameter set is wrong.
71 CRC1 error
Tab. 1.3-17 Information contents of byte 11
The GSE file contains all information on the configuration of the PROFIBUS
system. This makes the integration easy and user-friendly.

Tip!
You will find the current GSE file for this Lenze product in the
Internet in the ”Downloads” area under
http://www.Lenze.com
Diagnostic information
GSE file
