Safety engineering
Device modules
Safety module SM300
1
1.2
1.2.3

1.2-6 EDS94AYAD EN 2.2
Cable cross-sections and tightening torques
Type
[mm 2 ] [Nm] AWG [lb-in]
Wire end ferrule,
insulated
0.25 ... 0.5
Spring terminal
24 ... 20
Spring terminal
Rigid 0.14 ... 1.5 26 ... 16
1.2.3.4 Technical data
The inputs are isolated and designed for a low-voltage supply of 24 V DC.
Detailed features of the inputs and outputs
Signal
Specification min. typ. max.
I1A, I1B
I2A, I2B
I4A, I4B
AIE
PLC input, IEC-61131-2, 24 V, type 1
LOW signal
[V] -3 0 5
Input current [mA] 15
HIGH signal [V] 15 24 30
Input current [mA] 2 15
Input capacitance [nF] 3.3
AIE Pulse duration [ms] 300 10 4
CLA, CLB PLC output, IEC-61131-2, 24 V DC, 50 mA
LOW signal output voltage
[V] 0 0.8
HIGH signal output voltage [V] 17 24 29
Output current [mA] 50
Width of the test pulse [μs] 750
Test pulse rate [s] 1.8
Cable resistance of a passive sensor [kΩ] 2
+, - Supply voltage of the module via a safely
separated power supply unit (SELV/PELV)
[V] 19,2 24 30
Input current [A]
Tab. 1.2-1 Technical data
The chapter ”Response times” must be observed as well ( 1.3.5.2).
1.2.3.5 Commissioning
ƒ Settings in or at the module:
– PROFIsafe target address switch
ƒ Required settings in the basic device:
– C00214, type of safety module
ƒ Integration of the SM300 into the drive application
ƒ During commissioning and after the replacement of a module it is vital
to check the safety function.
