6electrical installation – Lenze E94AYCPM User Manual
Page 40
Electrical installation
Wiring of the PROFIBUS
EDK94AYCPM DE/EN/FR/ES/IT 6.0
40
l
H1_E_INST−Steckerleiste_Schraubanschl_15
Specification of the transmission cable
)
Note!
Only use cables complying with the listed specifications of the PROFIBUS user
organisation.
Field
Values
Specific resistance
135 ... 165
W
/km, (f = 3 ... 20 MHz)
Capacitance per unit length
£
30 nF/km
Loop resistance
< 110
W
/km
Core diameter
> 0.64 mm
Core cross−section
> 0.34 mm
2
Cores
Twisted double, insulated and shielded
