24 CMVLC401A
Commissioning
9.2 Drive ID (P502)
This register returns an index value that is associated with the voltage and power rating of the drive. Table 10 lists the
drive configuration by Index number.
Table 10: Drive ID
Index Input Voltage Power Rating
8 240 VAC, Single-Phase 0.33 HP (0.25 kW)
12
240 VAC
Single or Three-Phase
1.5 HP (1.1 kW)
13 2 HP (1.5 kW)
14 3 HP (2.2 kW)
21
240 VAC
Three-Phase
0.5 HP (0.37 kW)
23 1 HP (0.75 kW)
24 1.5 HP (1.1 kW)
25 2 HP (1.5 kW)
26 3 HP (2.2 kW)
28 5 HP (4 kW)
29 7.5 HP (5.5 kW)
30 10 HP (7.5 kW)
31 15 HP (11 kW)
32 20 HP (15 kW)
42
480 VAC
Three-Phase
0.5 HP (0.37 kW)
44 1 HP (0.75 kW)
45 1.5 HP (1.1 kW)
46 2 HP (1.5 kW)
47 3 HP (2.2 kW)
49 5 HP (4 kW)
50 7.5 HP (5.5 kW)
51 10 HP (7.5 kW)
52 15 HP (11 kW)
53 20 HP (15 kW)
54 25 HP (18.5 kW)
55 30 HP (22 kW)
69
600 VAC
Three-Phase
1 HP (0.75 kW)
71 2 HP (1.5 kW)
72 3 HP (2.2 kW)
74 5 HP (4 kW)
75 7.5 HP (5.5 kW)
76 10 HP (7.5 kW)
77 15 HP (11 kW)
78 20 HP (15 kW)
79 25 HP (18.5 kW)
80 30 HP (22 kW)
91
120 or 240 VAC
Single-Phase
0.33 HP (0.25 kW)
92 0.5 HP (0.37 kW)
94 1 HP (0.75 kW)
All unused Index values are reserved for future use
