Commissioning
4.2
RS485 LECOM-Specific Parameters
The parameters listed in Table 6 are only present in the drive if there is an RS485 communication module installed,
P400 = 7 and the module is online (P402 = 3).
Table 6: RS485 LECOM-Specific Parameters
Code
Possible Settings
IMPORTANT
No.
Name
Default Selection
P410
Network address
1
1
99
The values 00, 10, 20, 30 … 90 must not
be used since they are reserved for group
addressing (see section 6.4).
P411
Network
Baud Rate
0
0 9600 bps
1 4800 bps
2 2400 bps
3 1200 bps
4 19200 bps
P420
Network Control
Level
0
0 Monitor Only
P420 =2, 3: setpoint control using code
number C0046 or C1061.
P420 = 3, 4: drive control using code
numbers C0040 and/or C0135
P420 = 4: setting C0140 = 0 results in
Quick Stop
Stop commands (QUICK STOP, INHIBIT)
will always be accepted.
1 Parameter Programming
2 Programming and Setpoint Control
3 Full Control
4 Full Control (Special)
P424
Network Powerup
Start Status
0
0 Quick Stop
1 Controller Inhibit
P425
Network Message
time-out
50
0
{ms}
65000
P426
Network Message
time-out action
0
0 No action
1 Controller Inhibit
2 Quick Stop
3 Trip Fault, F.nF1
P427
Valid Network
messages
Received
0
0
{messages} 9999
• Read-only
• When number of messages exceed
9999, counter resets and resumes
counting from 0.
P494
Communication
Module software
version
• Read only
• Format: x.yz
P495
Internal Code
• Read only
• Alternating Display: xxx-; -yy
