23 RG-SDMOD
Drive Control & Communication
Parameter No.
1 smd Register #
(hexadecimal
representation)
Parameter Name Range of Adjustment 2,
Modbus value (decimal value)
Factory
Default
PV400 PV507
c25 95 (5FH) 103 (67H) LECOM Baud Rate 0 9600 bps (9600, 8, N, 2 if C01 = 8...11)
1 4800 bps (9600, 8, N, 1 if C01 = 8...11)
2 2400 bps (9600, 8, E, 1 if C01 = 8...11)
3 1200 bps (9600, 8, O, 1 if C01 = 8...11) 0
c38 105 (69H) PI Actual Setpoint c86 - c87 Read Only
c40 97 (61H) 106 (6AH) Freq. Setpoint Command 0 - 2400 (0.0 - 240 Hz) 0.0 Hz
c42 98 (62H) 107 (6BH) Start Condition 0 Start after LOW-HIGH chnage at 28
1 Auto Start if 28 = HIGH 1
c60 109 (6DH) Mode Select for c61 0 Monitor Only
1 Monitor and Edit 0
c61 100 (64H) 110 (6EH) Present Fault Status / Error Message (refer to Note 5) Read Only
c62 101 (65H) 111 (6FH) Last Fault Error Message (refer to Note 5) Read Only
c63 102 (66H) 112 (70H) Last but one Fault Error Message (refer to Note 5) Read Only
c70 103 (67H) 113 (71H) Configuration
TRIP Reset
0 TRIP reset by LOW-HIGH signal at 28 or mains
switching or LOW-HIGH signal at digital input
"TRIP reset"
1 Auto TRIP reset
0
c71 104 (68H) 114 (72H) Auto TRIP Reset Delay 0 - 600 (0.0 - 60.0 sec) 0.0 sec
c78 105 (69H) 115 (73H) Operating Time Counter Read Only
c79 106 (6AH) 116 (74H) Mains Conn Time Counter Read Only
c81 117 (75H) PI Setpoint c86 - c87 0.0
c82 118 (76H) S-Ramp Integral Time 0 - 500 (0.0 - 50.0 sec) 0.0 sec
c86 119 (77H) PI Min Feedback 0 - 9990 (0.0 - 999.0) 0.0
c87 120 (78H) PI Max Feedback 0 - 9990 (0.0 - 999.0) 100.0
d25 123 (7BH) PI Setpoint Accel/Decel 0 - 9990 (0.0 - 999.0 sec) 5.0 sec
d38 124 (7CH) PI Enable 0 PI Disabled
1 PI Enabled - Normal Acting
2 PI Enabled - Reverse Acting 0
d46 125 (7DH) PI Min Alarm 0 - 9990 (0.0 - 999.0) 0.0
d47 126 (7EH) PI Max Alarm 0 - 9990 (0.0 - 999.0) 0.0
n20 113 (71H) 131 (83H) LECOM Power-Up State 0 Quick Stop
1 Inhibit 0
n22 114 (72H) 132 (84H) Serial Timeout Action 0 Not Active
1 Controller Inhibit
2 Quick Stop
3 Trip Fault "FC3" 0
n23 115 (73H) 133 (85H) Serial Fault Time 50 - 65535 ms 50 ms
1 = The drive's programming code number; 2 = Selections in bold are for smd models with PV507 only.
