17 RG-SDMOD
Drive Control & Communication
5.4.5 Speed Command Source - Registers #24 & 28
Table 14 lists the Speed Command Source (Register #24 byte D5H or Register #28 DH).
Table 14: Speed Command Source
Setting Source
0 ANALOG FREQ.
1 PRESET c40
2 PRESET 1
3 PRESET 2
4 PRESET 3
5 MOP SPEED
6 SERIAL SPEED
5.4.6 Speed Reference Status - Registers #24 & 28
Table 15 lists the Speed Reference Status (Register #24 byte D5L or Register #28 DL).
Table 15: Speed Reference
Setting Status
0 SERIAL SPEED REFERENCE
1 LOCAL SPEED REFERENCE
5.4.7 Present Fault - Registers #24 & 29
Table 16 lists the Present Fault (Register #24 byte D6H of Register #29 DH)
Table 16: Present Fault
Setting Fault Display Setting Fault Display
0 NO FAULT 14 INTERNAL FAULT 5 F5
1 OUTPUT (TRANSISTOR) FAULT OC1 15 INTERNAL FAULT 6 F6
2 HIGH DRIVE TEMPERATURE OH 16 INTERNAL FAULT 7 F7
3 HIGH DC BUS VOLTAGE OU 17 INTERNAL FAULT 8 F8
4 LOW DC BUS VOLTAGE LU 18 INTERNAL FAULT 9 F9
5 THERMAL OVERLOAD OC6 19 INTERNAL FAULT o Fo
6 CONTROL FAULT CF 20 SINGLE PHASE FAULT SF
7 EXTERNAL FAULT EEr 21 INCOMPATIBILITY FAULT cF
8 SERIAL COMMUNICATION FAILURE FC5 22 DYNAMIC BRAKE OVERHEATED dF
9 START ERROR LC 23 REMOTE KEYPAD FAULT JF
10 INTERNAL FAULT 1 (EPM) F1 24 COMMUNICATION FAULT FC3
11 INTERNAL FAULT 2 F2 25 EARTH FAULT OC2
12 INTERNAL FAULT 3 F3 26 CONFIGURATION FAULT CFG
13 INTERNAL FAULT 4 F4
