Page 51
Mechanical installation
5
EDK84AZESRx DE/EN/FR/ES/IT 2.0
51
l
H1_MechINS−FE−Filt_84_Var_Mont_Schritte
5
Mechanical installation
)
Note!
The filter can be mounted in two ways. From this result different mounting
dimensions.
ƒ
Standard mounting: The filter is mounted underneath the standard device.
ƒ
Side−by−side mounting: In case of a low depth of the control cabinet, the
filter is rotated by 90° and mounted to the left side of the standard device.
