Product description
Scope of supply
3
l
27
MA_CSx8xx DE/EN/FR/ES/IT 2.0
3
Product description
3.1
Scope of supply
Quantity Name
1
Command station
1
Connection plug for voltage supply
1
Fixing adapter (option)
1
DVD "PC based Automation"
1
Test report
1
Device pass card
3.2
Controls and displays
Status
F1
Fail
+
-
F3
F2
Power
0
1
8
7
6
5
4
PS/2
LAN
RS232
ACU UPS
24 V DC
CF Card
MC Card
Reset
USB
2 3
9
CS57x0−001
Pos.
Description
0
Command Station (here CS 5800)
1
Mounting frame
2
PC
3
Screen
4
Status LEDs (Error, HD, Power)
5
Front face status LEDs (Power, Fail, Status)
6
Front face control and display elements
7
Front face USB port (option)
8
Mounting frame connecting plate (option)
9
Nameplate
