Leica S Series User Manual 21
The optional graticules enable measure-
ment and, in addition, provide valuable
information when comparing and capturing
still images of the specimens. Insert the grati-
cule before you set the eyepiece in place.
Available Graticules
The following graticules and objective micro-
meters for calibrating may be ordered:
O Graticule 10 mm/0.1 mm
O Graticule 5 mm/0.1 mm
O Graticule 5 mm/0.05 mm
O Graticule 100 Div./0.002"
O Graticule 100 Div./0.001"
O Graticule 150 Div./0.0005"
O Crosshairs
O Stage micrometer 50 mm, 0.1/0.01/ mm
graduation
O Stage micrometer 1", 0.001" graduation
