ELECTRICAL SPECIFICATIONS
DC Voltage Measurement
Range Resolution Accuracy
600mV ˜ ˜ 600V 0.1mV ˜ 100mV ± (0.5% + 4 digits)
1000V 1V ± (0.8% + 10 digits)
Overload Protection: 1000V
AC Voltage Measurement
Range Resolution Accuracy
600mV ˜ ˜ 750V 0.1mV ˜ ˜ 1V ± (2.0% + 5 digits)
Overload Protection: 750V RMS Frequency Response: 45 to 400 Hz
Minimum Voltage for Frequency Measurement: 200mV
Response: True RMS
DC Current Measurement
Range Resolution Accuracy
600µA 0.1µA
± (1.2% + 3 digits)
2000µA 1µA
60A 0.01A ± (2.5% + 15 digits)
600A 0.1A ± (1.5% + 8 digits
Overload Protection:
• Voltage: 600V RMS
• Current: 2000µA Clamp 600A
AC Current Measurement
Range Resolution Accuracy
600µA 0.1µA ± (2.0% + 5 digits)
2000µA 1µA ± (1.5% + 5 digits)
60A 0.01A ± (2.9% + 15 digits)
600A 0.1A ± (1.9% + 8 digits)
Overload Protection:
• Voltage: 600V RMS
• Current: 2000µA Clamp 600A
Frequency: 45 to 400Hz
Minimum Current for Frequency Measurement: 400µA or 20A
Minimum Current for Clamp Measurement: 0.2A
Response: True RMS
Resistance Measurement
Range Resolution Accuracy
600 Ω
˜ 6M ˜˜
Ω 0.1 Ω
˜ 1k ˜˜
Ω ± (1.0% + 4 digits)
60M Ω 10k Ω ± (2.0% + 4 digits)
Overload Protection: 600V RMS
Capacitance Measurement
Range Resolution Accuracy
60nF ˜ 6000µF
˜˜
0.01nF ˜ 1µF
˜˜
± (3.5% + 6 digits)
Overload Protection: 600V RMS
Frequency Measurement (Voltage)
Range Resolution Accuracy
99.99Hz ˜ 499.9kHz
˜˜
0.01Hz ˜ 100Hz
˜˜
± (0.1% + 4 digits)
Overload Protection: 600V RMS Sensitivity: 2.5V RMS
