Page - 5
DISPLAY FACEPLATE
chargeGUARD Display has a detachable faceplate. It can be painted to
match your dash color, or additional faceplates in optional colors can be
ordered separately.
There are (4) latches, which hold the
faceplate securely to Display housing.
Insert a small jewelers screwdriver in
each of the detents to release latch,
one at a time.
Once the faceplate is loose, carefully
lift it up and away from the Display
housing, leaving the rubber keypad in
place.
When reinstalling, first hook the lower
(2) latches then pivot the faceplate
toward the top (2) latches.
Once it is flush, push it in place until
the detents hold the faceplate down
securely.
Note! If the keypad is disturbed from it’s location, water barrier seal
can be compromised.
