Page - 14
CHARGING CYCLES
I
OUT (MAX)
V
OUT (NOM)
Standby Mode
Battery not
connected
0 Amp 0 Volts
Constant
Current Mode Fast Charge
Cycle
1.1 Amp
14.7
Volts
Constant
Voltage Mode Equalization
Cycle
0.2 Amp
14.1
Volts
Floating Charge
Mode Voltage
Maintenance S
0.05Amp 13.8
Volts
Accessories included with each chargeX
mini
Eyelet Connector
Mount the Red ring connector on the positive post,
and the Black ring connector to the negative post
of the battery. The polarized plug can be easily
hooked-up for charging.
Alligator Connector
The Red alligator clips on the positive post and the
Black alligator clips on the negative post. Do not
ride with alligator clips attached, they are to be
used as temporary hook-up only.
AC Plug Adapters
One of the plugs shown
is included. Additional
adapters can be
purchased separately.
