MODE SELECTIONS
chargeGUARD display has a single
button scroll feature to allow easy mode
change while you are riding - even with
gloves on.
The default mode for each engine start is
the Voltmeter function. After that, it will
remain in whichever mode you select.
Until you change it or restart the engine.
Push the Mode button to sequence the display functions:
VOLTMETER FUNCTION:
Displays battery voltage from 0 to 19.9 volts.
Bar-graph range is: 10 to 14 volts.
AMMETER FUNCTION:
Displays current flow at battery post, ± 99 Amps.
Bar-graph range is: 3 to 15 Amps.
TEMEPERATURE FUNCTION:
Displays ambient temperature in Fahrenheit.
The range is: -40º F to +120º F
TEMEPERATURE FUNCTION:
Displays ambient temperature in Centigrade.
The range is: -10º C to +75º C
If you have NOT INSTALLED the Current Sensor or the Temperature Sensor, or
if they are disconnected, those functions will not be displayed.
