Kargo Master PRO III Ladder Rack for Ford TC (80070) User Manual
Page 3
N
B
(4 ea.)
1/2" Nyloc Jam Nut
©2012 KARGO MASTER_TMCS 3:1
A
(4 ea.)
1/2" x 2 1/4"
Button Head Bolt
(4 ea.)
Mounting Bracket Spacers
M
(4 ea.)
3/8" Lock Nut
K
(4 ea.)
3/8" x 4"
Hex Bolt
(4 ea.)
1/2" SAE Flat Washer
P
(8 ea.)
3/8" SAE Flat Washer
L
G
(8 ea.)
5/16" x 3/4"
Button Head Bolt
H
(8 ea.)
5/16" Lock Washer
I
(32 ea.)
5/16" Flat Washer
E
(16 ea.)
5/16" x 1"
Carriage Bolt
J
(24 ea.)
5/16" Lock Nut
S
(8 ea.)
5/16" x 1 1/4"
Button Head Bolt
80070 Bolt Kit
D
(4 ea.)
M8 x 32
