Kargo Master PRO III Ladder Rack for Ford TC (80070) - Manual (Page 2)

Shaded numbers ( ) in this view
correspond to instruction steps in this
assembly package.
NOTE:
2012 KargoMaster-TMCS-3:1
80070 Top Mount
Camper Shell & Transit
Connect Rack
ASSEMBLY INSTRUCTIONS
Read all instructions carefully and follow each
step in proper sequence for ease and speed in
assembling your
KARGO-MASTER RACK.
See below for nuts and bolts diagram.
B
L
GOOP
3
2
5
4
11 11
88
WARNING!
WE RECOMMEND THAT YOU NOT EXCEED 200 LBS. OF EVENLY
SPACED CARGO. TOO MUCH WEIGHT COULD DAMAGE YOUR
CAMPER SHELL. KARGO MASTER MAKES NO REPRESENTATION
OR WARRANTY AS TO THE AMOUNT OF WEIGHT THAT CAN BE
CARRIED SAFELY BY OR WITHOUT DAMAGING YOUR SHELL. FOR
GUIDANCE, WE RECOMMEND THAT YOU CONSULT THE CAMPER
SHELL MANUFACTURER.
DRILLING HOLES IN THE CAMPER SHELL ROOF MAY VOID THE
WARRANTY. WE RECOMMEND THAT YOU HAVE AN AUTHORIZED
CAMPER SHELL DEALER DRILL AND MOUNT THE RACK FOOT
PLATES.
SECURE ALL CARGO PROPERLY FOR SAFE TRANSPORTATION.
