Technical data (general)

Technical data (transmitter)

Input

Measurement input

without transmitter:
Pt100 or Pt1000 temperature sensor, EN 60751, Class A, B or AA (1/3 Class B),
2- or 4-wire circuit
with programmable transmitter:
Pt1000 temperature sensor, EN 60751, Class A,
4-wire circuit

Measuring ranges

Basic type 902815/10... : -50 to +200 °C
Basic type 902815/20... : -50 to +150 °C
Basic type 902815/21... : -50 to +260 °C with extension

Tolerance limits

0.15 + 0.002 × |t|

1

, Class A (standard)

0.10 + 0.0017 × |t|

1

, Class AA (1/3 Class B)

0.30 + 0.005 × |t|

1

, Class B

Environmental influences

Ambient temperature range for the head

Basic type 902815/10... : -30 to +90 °C
Basic types 902815/20... and 902815/21... : -30 to +85 °C

Storage temperature range

-30 to +90 °C

Climatic conditions

according to IEC 68-2-30 (rel. humidity

95 % with condensation)

Vibration strength

according to IEC 68-2-6 (according to GL characteristic)

Input

Shortest span

10 K

Sampling rate

1 measurement per second

Input filter

1st order digital filter; filter constant adjustable from 0 to 125 s

Measuring circuit monitoring

Underrange

linear fall off to 3.8 mA (according to NAMUR recommendation 43)

Overrange

linear rise up to 20.5 mA (according to NAMUR recommendation 43)

Probe short-circuit, probe or lead break

3.6 mA or

21.0 mA (configurable)

Current limiting for probe short-circuit
or probe break

25 mA

Output

Output signal

proportional DC current 4 to 20 mA or 20 to 4 mA

Transfer characteristic

linear with temperature

Maximum burden resistance (R

B

)

R

B

= (U

b

- 8 V) / 23 mA, max. 600

Ω

Burden error

±0.02 %/100

Ω

2

Settling time after temperature change

5 s

Settling time after switch-on or reset

5 s

Measuring accuracy for electronics

0.1 °C or 0.08 %

3

Electrical data

Voltage supply (U

b

)

8 to 35 V DC (pin 1 = +, pin 3 = -),
only for operation in SELV or PELV circuits according to EN 50178

Reverse polarity protection

yes

Voltage supply error

± 0.01 % per V deviation from 24 V

2

Environmental influences

Ambient temperature error

±(15 ppm/°C × (range end + 200) + 50 ppm/°C × set range) ×

Δυ

Δυ

= deviation of ambient temperature from the reference temperature

Calibration/reference conditions

24 V DC at 25 °C ± 5 °C (77 °F ± 9 °F)

Electromagnetic compatibility (EMC)
- interference emission
- interference immunity

EN 61326
Class B
industrial requirements

1

|t| is the numerical value of the temperature in °C, disregarding the sign.

2

% details refer to the end of range value 20 mA.

3

% details refer to the measuring span that has been set, the larger value applies.
