Technical data

General information

Control ranges and limit values

Control range / limit value

Ventilator controller

Burner monitor

Protection temperature limiter S

TR - system 2
+20 to +80 °C

TW - system 2
+70 to +90 °C

STB - system 80 or 40
limit value 100 °C

Capillary and temperature probe

Capillary

Material: copper (Cu), material No. 2.0090

Diameter: Ø 1.5 mm

Capillary length including probe: 350 mm with support tube, 1250 mm without support tube

a

a

Probe identification for the version with capillary: ventilator controller TR: red; burner monitor TW: blue

Minimum bending radius: 5 mm

Temperature probe

Material: copper (Cu), material No. 2.0090, hard soldered

Diameter: 3 probes Ø 4 mm

Electrical data

Switching element

Ventilator controller
burner monitor

Safety temperature limiter STB

System 80

Safety temperature limiter STB

System 40/U

Microswitch with changeover
contact

Microswitch with N/C contact and
restart lock

Microswitch with N/C contact,
restart lock, and additional signal
contact

Maximum contact rating

AC 230 V +10 %, 10 (2) A, cos

ϕ = 1 (0.6)

DC 230 V +10 %, 0.25 A

Electrical connection

Via terminal rail, after removing the case lid, temperature controller and terminal rail are mounted to a PCB
(epoxy resin glass fabrics) with printed diagram

Operating data

Switching differential

Switching function: Ventilator controller TR

14

± 2 K

Burner monitor TW

6

± 1 K

Switching point accuracy

Switching function: In the upper third of the scale

or limit value

At the scale beginning

Ventilator controller TR:

± 4 K

± 6 K

Burner monitor TW:

± 4 K

± 4 K

Safety temperature limiter STB: +0/-5 K

− − −

Ambient temperature
influence

On the switching head:

On the capillary:

0.35 K/K
per meter: 0.07K/K

Operating medium

Air

Time constant

In air:

≤ 120 s

Over-temperature security

At the temperature probe +200 °C

Admissible storage
temperature

-50 to +50 °C

Admissible ambient
temperature for use

Max. +80 °C

Rated position

Acc. to DIN 16 257, rated position 0 to rated position 90 (different rated position on request)

Comment

To achieve the full response accuracy, only use the device without the probe thermowells. The temperature
probes of the device must be completely submerged into the operating medium to be monitored.
