Stock versions
(11) Capillary length 1
0 0 mm design type 6, rigid thermowell
1000 1000 mm
3000 3000 mm
. . . . (Special length, specifications in plain text, 1000 mm increments)
(12) Capillary length 2
0 0 mm (only design type 6 and for single thermostat)
1000 1000 mm
3000 3000 mm
. . . . (Special length, specifications in plain text, 1000 mm increments)
(13) Capillary material
20 Stainless steel (CrNi)
(14) Process connection (PC)
10 Plain cylindrical probe
15 Spiral probe
74 Mounting adaptor
(thermowells can be ordered separately according to data sheet 605057
(with Ex-approval) or data sheet 606710 (standard)
(15) Diameter 1 "d" (single thermostat)
4 Ø 4 mm
6 Ø 6 mm
56 Ø 56 mm
(16) Diameter 2 "d" (double thermostat)
0 Without
4 Ø 4 mm
6 Ø 6 mm
(17) Insertion length "S"
0 Without thermowell
200 200 mm
300 300 mm
(18) Extra codes
000 Without extra code
372 IECEx Approvals (extra code 861 not available)
861 IP66 (extra code 861 not available)
Order code:
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (16) (17) (18)
605055 / . . . . - . - . - . . . - . . . - . . - . . - . . - . . - . . . . - . . . . - . . - . . - . . - . . - . . . / . . . , . . .
Order example:
605055 / 2070 - 5 - 4 - 028 - 064 - 21 - 467 - 25 - 00 - 1000 - 1000 - 20 - 10 - 4 - 4 - 200 / 000 , . . .
Part no. Type Control range °C Measuring system
material
Capillary length Probes
60003365 605055/20 (STW) -20 to +50
CrNi
1000 mm 6 x 81 mm
60003366 605055/02 (TW) -20 to +40 - - Spiral probe
60003367 605055/20 (STW) 0 to +120 1000 mm 6 x 58 mm
60003368 605055/20 (STW) +50 to +300 1000 mm 4 x 78 mm
60003369 605055/2070 (STW/STB)
0 to +200 (STW)
1000 mm
4 x 87 mm (STW)
+50 to +300 (STB) 4 x 78 mm (STB)
60003391 605055/20 (STW) 0 to +200 1000 mm 6 x 48 mm
60003395 605055/0070 (STB) 0 to +200 1000 mm 6 x 48 mm
60003401 605055/0002 (TW) 0 to +200 1000 mm 6 x 154 mm
