Order details
Explosion-proof panel-mounted thermostat JUMO exTHERM-AT
Order code (1) Basic type
605055 Surface-mounted thermostat JUMO exTHERM-AT for potentially explosive areas
(2) Basic type extensions
0002 Temperature monitor (TW)
0020 Safety temperature monitor (STW)
0070 Safety temperature limiter (STB)
0270 Temperature monitor (TW) / safety temperature limiter (STB)
2070 Safety temperature monitor (STW) / safety temperature limiter (STB)
(3) Design type
5 Surface-mounted thermostat
6 Room thermostat
(4) Case
4 Polyester case black (standard)
6 Stainless steel case
(5) Control ranges / limit value ranges 1 in °C
013 -20 to +40 (only room thermostat)
014 -20 to +50
026 0 to +120
028 0 to +200
046 +20 to +500 (only TW)
064 +50 to +300
539 +140 to +500 (only STW and STB)
532 +130 to +190
(6) Control ranges / limit value ranges 2 in °C
000 (only single thermostat)
013 -20 to +40 (only room thermostat)
014 -20 to +50
026 0 to +120
028 0 to +200
046 +20 to +500 (only TW)
064 +50 to +300
539 +140 to +500 (only STW and STB)
532 +130 to +190
(7) Switching capacity
11 AC / DC = 24 V, 100 mA (gold-plated snap-action switch)
21 AC 230 V +10 %, 16 (2.5) A, cos ϕ = 1 (0.6) (standard)
41 AC 400 V +10 %, 16 A
25 AC 230 V +10 %, 25 (4) A, cos ϕ = 1 (0.6)
(8) Operating temperatures in °C
340 -55 to +40 T6 (+70 °C T4) (+50 °C T4 at 25 A)
467 -40 to +40 T6 (standard) (+70 °C T4) (+50 °C T4 at 25 A)
(9) Switching differential 1
00 Without switching differential (STB)
25 Approx. 2.5 % (TW)
70 Approx. 7 % (TW, STW)
(10) Switching differential 2
00 Without switching differential (STB) and for single thermostat
25 Approx. 2.5 % (TW)
70 Approx. 7 % (TW, STW)
