6 Instrument description
26
Nominal
position unrestricted
Weight approx. 0.2 kg
Capillary and
probe material
Minimum
bending radius
of capillary
5 mm
Mean
ambient
temperature
error in % of scale span, referred to the limit value.
A deviation of the ambient temperature at the switch head and/or the capillary
from the +22 °C calibration ambient temperature produces a shift in the
switching point:
higher ambient temperature = lower switching point
lower ambient temperature = higher switching point
Temperature
compensation
(extra code 707)
Please see the diagram in Data Sheet 602021 for details.
End of scale Capillary Probe
up to +200 °C copper, Mat. Ref. Cu-DHP
1.5 mm diameter copper, Mat. Ref. Cu-DHP
brazed
up to +350 °C copper, Mat. Ref. Cu-DHP
1.5 mm diameter stainless steel,
Mat. Ref. 1.4571
brazed
up to +500 °C stainless steel,
1.5 mm diameter stainless steel,
Mat. Ref. 1.4571
welded
at extra cost
up to +350 °C stainless steel,
1.5 mm diameter stainless steel,
Mat. Ref. 1.4571
welded
For temperatures with end of scale / limit value
< +200 °C
≥ +200 °C ≤ +350 °C ≥ +400 °C ≤ +500 °C
TR, TW, TB STW
STB
TR, TW, TB STW, STB TR, TW, TB
STW, STB
Switching differential in %
1 / 2.5 5 7 7 / - - 1 / 2.5 5 7 / - - 3.5 6 10
Ambient temperature effect due to the switch head, % per °C
0.15 0.26 0.34 0.43 0.12 0.21 0.35 0.12 0.17 0.24
Ambient temperature effect due to the capillary, % per °C per meter
0.05 0.09 0.04 0.07 0.05
