23

6 Instrument description

6.1

Technical data

Permissible
ambient
temperature

Permissible
probe
temperature

max.: end of scale / limit value +15%,

(for end of scale between +90 °C and 120 °C = min. 25 °C

min.: -50 °C (on STW(STB) and STB -35 °C)

Permissible
storage
temperature

max. +50 °C, min. -50 °C

Housing

galvanized steel sheet

Switching
device

Capillary

Switch head

for end of scale

TR,TW

TB,

STW(STB)

STB

TR,TW

TB,

STW(STB)

STB

max.

see nameplate

min.

-40 °C

-20 °C

-20 °C

0 °C

< 200 °C

-20 °C

≥ 200 °C ≤ 350 °C

-40 °C

> 350 °C ≤ 500 °C

Type EM-....

Description
1, 2, 3 or 4 single-pole snap-action switches

1, 2, 3, 20, 30

with changeover contact

4, 5, 40, 50

with n.c. (break) contact

4/574, 5/574, 40/574,
50/574

n.c. (break) contact with additional signal contact
