3 Mounting
12
Type EM.-4, -5,
-40 or -50
central fixing
(extra code 710) ( 1 ) Panel
( 2 ) Fixing nut
M10 x 1 (13 a/f)
(3) Cap nut M10 x 1
(10 a/f)
(4) Reset button
Type Dim. (mm)
X Y
EM-4, -5
16
6
EM-40, -50, 11
( 1 )
( 2 )
( 3 )
( 4 )
