Data Sheet 602021
2014-01-20/00073206
Page 4/14
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address:
36035 Fulda, Germany
Phone:
+49 661 6003-0
Fax:
+49 661 6003-607
E-mail:
Internet:
www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail:
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax:
315-437-5860
E-mail:
Internet: www.jumousa.com
Electrical data
Operating data
Switching element
1, 2, 3, or 4
single-pole
snap-action switches
EM.-1...
EM.-2...
EM.-3...
EM-20
EM-30
EM.-4...
EM.-5...
EM-40
EM-50
EM.-4.../U
EM.-5.../U
EM-40/U
EM-50/U
Microswitch with
changeover contact
Microswitch with N/C contact
and restart lock
Microswitch with N/C contact,
restart lock,
and additional signal contact
Max. contact rating
Switching function
Switching differential
N/C contact,
terminal 2
N/O contact,
terminal 4
TR, TW, STW (STB)
2.5 %, 5 %, 6 %, 7 %, 10 %
AC 230 V +10 %
16 (3) A, cos
ϕ = 1 (0.6)
DC 230 V +10 %, 0.25 A
AC 230 V +10 %
8 (1.5) A, cos
ϕ = 1 (0.6)
DC 230 V +10 %, 0.25 A
TB, STB
AC 230 V +10 %
2 (1) A, cos
ϕ = 1 (0.6)
DC 230 V +10 %, 0.25 A
TR, TW
1 %, 3 %
AC 230 V +10 %, 6 (2) A, cos
ϕ = 1 (0.6)
DC 230 V +10 %, 0.25A
TR, TW
2.5 %
Microswitch with gold plating, extra code "702"
AC/DC 24 V, 0.1 A
Contact reliability
To ensure the greatest possible switching reliability we recommend a minimum load of:
For silver contacts:
AC/DC = 24 V, 100 mA
For gold-plated contacts (abbreviation "702"):
AC/DC = 10 V, 5 mA
Rating surge voltage
2500 V (via the switching contacts 400 V)
Overvoltage category
II
Required fuse rating
See max. switching capacity
Electrical connection
Standard
Tab connector A 6.3 × 0.8 DIN 46 244
Extra code 699
Screw connection up to 2.5 mm
2
conductor cross section
(available at extra cost) - also suitable for retrofitting -
Switching differential
in % from the
control range/
limit value range
Switching function
With liquid-filled measuring system
Rated value
Possible actual value
TR, TW
2.5
approx. 2.5 - 3.5
Standard
5
approx. 5 - 6
Upon request
7
approx. 7 - 8
Upon request
1
approx. 1 - 2
Surcharge
With gas-filled measuring system
5
approx. 5 - 11
Standard
6
approx. 6 - 14
Upon request
10
approx. 10 - 16
Upon request
3
approx. 2.5 - 4
Surcharge
STW (STB)
With liquid-filled measuring system
5
approx. 5 - 7
Standard
With gas-filled measuring system
6
approx. 6 - 16
Standard
Sequence contact
gap on multi-pole
version
With switching differential
Sequence contact gap relative to scale range
Switching point accuracy
of the sequence contact
gaps from the scale range
Minimum
Maximum
1 %
2.5 %
3 %, 5 %
6 %, 7 %, 10 %
1 %
1 %
2 %
3 %
According to
control range table
≤ 1 %
≤ 1 %
< 2 %
< 3 %
The spacing of the additional contacts can be specified in °C in relation to the setpoint of contact 1.
Prefix - = switching before reaching the setpoint value
Prefix + = switching after reaching the setpoint value
For the synchronized version, specify "0" as the sequence contact gap
