Data Sheet 602021
2014-01-20/00073206
Page 14/14
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address:
36035 Fulda, Germany
Phone:
+49 661 6003-0
Fax:
+49 661 6003-607
E-mail:
Internet:
www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail:
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax:
315-437-5860
E-mail:
Internet: www.jumousa.com
* State extra codes one after another, separated by commas.
Order code
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
602021
/
....
-
...
-
...
-
..
-
....
-
..
-
..
-
..
-
..
-
...
-
..
-
.
/
...
,
...
,
...
Order example
602021
/ 0005 - 052 - 000 -
00
- 2000 -
40
-
10
-
00
-
00
- 000 -
00
-
6
/
574*
, 710
Order details:
Panel-mounted thermostats, EM series
Order code
(12)
Diameter "D" (immersion tube diameter)
00
Without thermowells
0
8
8 mm
10
10 mm
(13)
Diameter "d" (probe diameter)
6
6 mm
8
8 mm
(14)
Extra codes*
000
Without extra codes
574
U Microswitch with N/C contact, restart lock, and additional signal contact (only for TB and STB)
702
au Snap-action switch contact, gold plated (only with 1-pole and 2-pole version)
699
X
Screw connection up to 2.5 mm
2
conductor cross section
704
b1 Switching head mounting with 2 M4 screws, spaced 28 mm
705
b2 Switching head mounting with 2 M3 screws, spaced 33 mm
710
b7 Central mounting with acorn nut (only for TB and STB)
707
TK Temperature compensation (only with 1-pole and 2-pole version)
* State extra codes one after another, separated by commas
Sequence contact gap for 2-pole, 3-pole, and 4-pole devices
Specify in plain text (e.g. +2 °C, +5 °C, +8 °C)
