Data Sheet 705001 Page 4/10
Technical data
Interfaces
Electrical data
USB device
Connector designation Setup
Connector type Mini-B
Number 1
Application Connection to a PC (setup program)
Max. current 100 mA
System bus Out
Connector designation Bus Out
Connector type RJ45
Number 1
Application Connection of a router module or a multifunction panel
Connection cable Network cable (patch or crossover cable), at least CAT5 (S/FTP)
Cable length Up to 100 m
Ethernet
Connector designation LAN
Connector type RJ45
Number 1
Application Communication with PC (setup program, web server), e-mail server, and Modbus
master/slave
Protocol TCP/IP, HTTP, DHCP, SMTP+POP3, Modbus/TCP
Transfer rate 10 Mbit/s, 100 Mbit/s
RS232 or RS422/485 (serial interfaces) Depending on the device type
Connector designation Com1 and Com2
Connector type D-Sub
Number 2
Application Fieldbus applications, communication via modem with a PC (setup program) or with
an e-mail server
Protocol Modbus RTU (master or slave);
PROFIBUS-DP (slave, Com2 only)
Transfer rate Modbus: 9600 Bd, 19200 Bd, 38400 Bd;
PROFIBUS: max. 12 Mbit/s
Voltage supply
Connection At the front (removable 2-pole terminal strip with Push-In technology)
Voltage DC 24 V +25/-20 % SELV
Residual ripple 5 %
Current consumption Max. 350 mA (at DC 19.2 V)
Current consumption of lined-up modules also has to be considered (see „Hardware
configuration“ in the setup program)!
Power consumption Max. 7 W
Conductor cross section (voltage supply)
Wire or strand without ferrule Min. 1.5 mm 2 , max. 2.5 mm 2
Strand with ferrule Min. 1.5 mm 2 , max. 2.5 mm 2
2 x strand with twin ferrule with plastic collar 1.5 mm 2
Stripping length 10 mm
Electrical safety Acc. to EN 61010-1
Overvoltage category III, pollution degree 2
